2007 Jeep JK Wrangler |
|
Assembly Plant |
Toledo, Ohio |
|
|
|
|
Engine |
3.8 liter, OHV, 12-valave SMPI V-6 |
Type and DescriptionHBZSEL28 |
Six-cylinder, 60° V-type, liquid-cooled |
Construction |
Cast-iron block, aluminum alloy heads |
Compression Ratio |
9.6:1 |
Power (SAE net) |
205 hp @ 5,200 rpm |
Torque (SAE net) |
240 lb.-ft. @ 4,000 rpm |
Oil Capacity |
6 qt. (5.7L) plus filter |
Alternator |
160A |
|
|
|
|
Transmission NSG 370 |
Manual, Six-Speed Overdrive |
Gear Ratios |
|
1st |
4.46 |
2nd |
2.61 |
3rd |
1.72 |
4th |
1.25 |
5th |
1.00 |
6th |
0.84 |
Reverse |
4.06 |
Axle Ratio |
3.21 Std., 4.10 Opt. (Std. on Rubicon) |
|
|
|
|
Transmission 42RLE |
Automatic, Four-Speed Overdrive |
Gear Ratios |
|
1st |
2.84 |
2nd |
1.57 |
3rd |
1.00 |
4th |
0.69 |
Reverse |
2.21 |
Axle Ratio |
4.10 |
|
|
|
|
Transfer Case NV241 |
Part-Time Command-Trac |
Operating Modes |
2WD High; 4WD High; Neutral; 4WD Low |
Low Range Ratio |
2.72:1 |
|
|
|
|
Transfer Case NV241 OR |
Part-Time Rock-Trac |
Operating Modes |
2WD High; 4WD High; Neutral; 4WD Low |
Low Range Ratio |
4.0:1 |
|
|
|
|
Exterior Dimensions |
|
Overall Length |
152.8 |
Overall Width w/o mirrors |
73.7 |
Overall Height, Hard Top (base tires) |
70.9 |
Wheelbase |
95.4 |
Track, Front |
61.9 |
Track, Rear |
61.9 |
Overhang, Front |
26.7 |
Overhang, Rear |
30.6 |
Turning Circle, ft. |
34.9 - all |
Suspension or Front Axle to Ground |
9.1 w/base tires
10.5 Rubicon |
Suspension or Rear Axle to Ground |
8.8 w/base tires
10.2 Rubicon |
Approach Angle - Degrees |
40.8 w/base tires
44.3 Rubicon |
Departure Angle - Degrees |
37.4 w/base tires
40.4 Rubicon |
Breakover Angle - Degrees |
21.8 w/base tires
25.4 Rubicon |
|
|
|
|
Interior Dimensions |
|
Seating Capacity - Front/Rear |
2/2 |
Front Headroom |
41.3 |
Front Leg Room |
41.0 |
Front Shoulder Room |
55.8 |
Front Hip Room |
55.6 |
Front Volume cu. ft. |
54.6 |
Couple - 1st Row to 2nd Row |
31.3 |
Rear Headroom |
40.3 |
Rear Leg Room |
35.6 |
Rear Shoulder Room |
61.6 |
Rear Hip Room |
44.7 |
Rear Volume cu. ft. |
48.3 |
Cargo Liftover Height |
27.8 |
Max. Cargo Width at
Swing
Gate Opening |
58.7 |
Min. Cargo Height at Swing
Gate Opening |
37.0 |
Max. Cargo Height at Swing
Gate Opening |
37.1 |
Distance Between Wheelhouses |
44.7 |
Cargo Volume cu. ft.
-
Rear Seat Installed |
56.5 |
Cargo Volume cu. ft.
- Rear Seat Removed |
61.2 |
Cargo Volume cu. ft.
Behind Rear Seat |
17.15 |
Maximum Payload
(includes occupants and cargo) |
1000 lbs. |
|
|
Curb Weight |
|
Wrangler X, Man. / Auto Trans. |
3760 lbs. / 3785 lbs. |
Wrangler Sahara, Man. / Auto Trans. |
3951 lbs. / 3976 lbs. |
Wrangler Rubicon, Man. / Auto Trans. |
4104 lbs. / 4129 lbs. |
|
|
|
|
Body and Chassis |
|
Layout |
Longitudinal front engine, four-wheel drive |
Construction |
Ladder-type frame, open steel body |
|
|
|
|
Suspension |
|
Front |
Live axle, leading arms, track bar, coil springs, stabilizer bar, low-pressure (on 16 inch wheel packages) gas-charged shock absorbers—std.; Monotube high-pressure (on 17 and 18 inch wheel packages)
gas-charged shock absorbers—std. Rubicon; Electronic Sway Bar Disconnect System (ASDS) opt
|
|
|
Rear |
Live axle, trailing arms, track bar, coil springs, stabilizer bar, low-pressure (on 16 inch wheel packages) gas-charged shock absorbers—std.; Monotube high-pressure (on 17 and 18 inch wheel packages) gas-charged shock absorbers—std. Rubicon
|
|
|
|
|
Steering |
|
Type |
Power, recirculating ball with damper |
Overall Ratio |
16.7:1 |
Turning Diameter (curb-to-curb) |
34.9 ft. |
Steering Turns (lock-to-lock) |
3.5 |
|
|
|
|
Brakes |
|
Power Assist Type |
10 (254) single-diaphragm vacuum |
Four-Wheel Anti-Lock with
on and off-road calibrations |
Standard |
Electronic Stability Program (ESP) |
Standard |
Parking Brake Type |
Drum-in-hat |
Front Size and Type |
11.9 x 1.1 vented rotor with 2.6 (66) single-piston floating caliper |
Swept Area (total front) |
190.8 sq. in. |
Rear Size and Type |
12.44 x 0.47 solid rotor with 1.9 (48) single-piston floating caliper |
Swept Area (total rear) |
55.4 sq. in. |
|
|
|
|
Wheels |
|
X |
16 x 7.0 |
Sahara |
17 x 7.5 (std.); 18 x 7.5 (opt.) |
Rubicon |
17 x 7.5 |
|
|
|
|
Tires |
|
X (standard) |
|
Size and Type |
P225/75R16, On/Off-road BSW |
Mfr. and Model |
Goodyear Wrangler ST |
X (optional) |
|
Size and Type |
P245/75R16, On/Off-road BSW |
Mfr. and Model |
Goodyear Wrangler SRA |
|
|
Sahara (standard) |
|
Size and Type |
P255/75R17, On/Off-road OWL |
Mfr. and Model |
Goodyear Wrangler SRA |
Sahara (optional) |
|
Size and Type |
P255/70R18, On/Off-road OWL |
Mfr. and Model |
Bridgestone Dueler 693 |
|
|
Rubicon |
|
Size and Type |
LT255/75R17, Off-Road BSW |
Mfr. and Model |
B.F.Goodrich Mud Terrain |
|
|
|
|
Towing |
|
Axle Ratio 3.21 |
1,000 lbs. |
Axle Ratio 4.10 |
2,000 lbs. |
|
|
Standard Equipment Features
•
3.8L, 205hp, OHV, 12-valve, SMPI V-6 gasoline engine
• Four-wheel Disc Anti-lock Braking System (ABS)
• Electronic Stability Program (ESP)
• Electronic Roll Mitigation
• 16-inch Painted Steel Wheels
• 17-inch Painted Cast Aluminum Wheels (Sahara)
• 17-inch Machined Cast Aluminum (Rubicon)
• P225/75R16, Goodyear Wrangler ST on/off-road black side wall tires
• P255/75R17, Goodyear Wrangler SRA on/off-road black side wall tires (Sahara)
• LT225/75R17, B.F. Goodrich Mud Terrain off- road black side wall tires (Rubicon)
• Compass and mini trip computer display (Sahara and Rubicon)
• 6-Speaker Audio System
• MP3 audio input jack
• Single-Hinge Center Pivot Windshield
• Rear under floor storage bin secured with lockable swing gate
• Sentry Key
• Rear Head Restraints
• Front Passenger Occupant Sensing
• Rock Rails (Rubicon) |
|
Available Equipment
• 2.8L direct-injection, Common-Rail Diesel Engine (export only)
• 5-Speed 545RFE optional with Diesel Engine (export only)
• 16 –inch Painted Cast Aluminum wheels
• 18-inch Painted Cast Aluminum wheels (Sahara)
• P245/75R16, Goodyear Wrangler SRA on/off road black side wall tires
• P255/70R18, Bridgestone Dueler A/T RH-S on /off road (Sahara)
• Larger, lockable floor console
• Driver’s Seat Height Adjuster (with cloth seats only)
• Power Windows and Door Locks
• 6-Disc CD/DVD System with MP3 Audio Capability
• Navigation System with Full Map Display and SIRIUS® Satellite Radio (late availability)
• Electronic Sway Bar Disconnect (On Rubicon)
• Rock Rails
• Factory-Installed Trailer Tow Package
• Modular 3-Piece Modular Hard Top
• Sun Rider Top
• NVH Reduction Packages
• Seat-Mounted Supplemental Side Airbags (not available with vinyl seats) |
